QUESTION 46
Which platform can be used to demo your solution to a customer? (Select three.)

QUESTION 47
The customer recently found out that Aruba OS-CX switches are capable of Application Recognition. What requirements should be fulfilled in order to do this? (Select two.)

QUESTION 48
The clients existing network is experiencing trouble with voice occasionally dropping out on phone calls between office locations, it Is determined that no packet loss is occurring and QOS is likely the cause. With what phenomenon Is the client currently experiencing issues?

QUESTION 49
Before beginning the design for HPE Aruba Networking Cloud Authentication at a distributed enterprise, you must gather information about the customer’s existing identity infrastructure and endpoint capabilities. The customer has expressed interest in a cloud-native authentication solution, but you have to gather details about their identity infrastructure or endpoint capabilities.
As the network architect, you need to move forward with initial planning by documenting reasonable assumptions about their current environment and their readiness to support cloud- native authentication.
Which assumptions would be appropriate to include at this stage to guide your design process?
(Choose two.)

QUESTION 50
A large multinational financial institution has contracted you to design a new full-stack wired and wireless network for their new 6-story regional office building. The bottom two floors of this facility will be retail space for a large banking branch. The upper floors will be carpeted office space for corporate users, each floor being approximately 100.000 sq ft (9290 sqm). Data centers are all off site and will be out of scope for this project. The customer is underserved by its existing L2-based network infrastructure and would like to take advantage of modern best practices in the new design. The network should be fully resilient and fault-tolerant, with dynamic segmentation at the edge. The retail space will include public guest Wi-Fi access. Retail associates will have corporate tablets for customer service, and there will be a mix of wired and wireless devices throughout the retail floors. The corporate users will primarily use wireless for connectivity, but several wired clients, printers, and hard VoIP phones will be in use. The customer is also planning on renovating the corporate office space in order to take advantage of “smart office’ technology. These improvements will drive blue-dot wayfinding. presence analytics, and other location-based services. The client decided that wired headless devices would be authenticated using Mac Authentication and would have RADIUS attributes sent back to the NAD to assign VLAN and port access parameters to the authentication session on the switch port. What would be critical in making this a successful deployment? {Select two.)

QUESTION 51
A large multinational financial institution has contracted you to design a new full-stack wired and wireless network for their new 6-story regional office building. The bottom two floors of this facility will be retail space for a large banking branch. The upper floors will be carpeted office space for corporate users, each floor being approximately 100,000 sq ft (9290 sqm). Data centers are all off site and will be out of scope for this project. The customer is underserved by its existing L2-based network infrastructure and would like to take advantage of modern best practices in the new design. The network should be fully resilient and fault-tolerant, with dynamic segmentation at the edge.
The retail space will include public guest Wi-Fi access. Retail associates will have corporate tablets for customer service, and there will be a mix of wired and wireless devices throughout the retail floors. The corporate users will primarily use wireless for connectivity, but several wired clients, printers, and hard VoIP phones will be in use.
The customer is also planning on renovating the corporate office space in order to take advantage of “smart office’ technology. These improvements will drive blue-dot wayfinding.
presence analytics, and other location-based services.
The client decided that they would like to manage two wiring closets as a single stack with a total of 10 switches and a minimum transport speed or 25Gbps over OM4 MM Tiber They would also like to keep the stacking cabling cost to a minimum. Which switch series would most economically accomplish these requirements?

QUESTION 52
You are responding to the customer’s RFP and are at the point of documenting design decisions that were not specified in the RFP or the RFP questions. What are valid examples of assumptions made that should be presented to the customer during the response? (Select three)

QUESTION 53
Which of the following best describes HPE’s Intelligent Resilient Framework (IRF)?

QUESTION 54
A global furniture retail company called ‘No-Stair Inc.’ requests you design their new WLAN infrastructure for a global footprint. Each location of ‘No-Stair Inc.” has a similar layout: three small manager offices, a warehouse, and a ‘retail’ area. The ‘retail’ area and the warehouse together amount to 95% of the location. The IT department of the company is minimally engaged in their LAN refresh so the CTO of the company has shared the information below.
Current WLAN Infrastructure is based on the 802.11n “WIFI4Less” access-points series (both model 2013-INT (2.4 only internal antenna) and model 2019-EXT (dual-band external antenna only). These AP models are standalone without any centralized management. Last year ‘No-Stair Inc.’ ran a project called ‘secure-it’ ensuring that all needed network security was implemented to be fully compliant with their security standards. During this project, they also upgraded the AAA.
Infrastructure to handle the increased AAA requests. No additional Wi-Fi or security requirements are listed for this WLAN refresh, which means that ‘No-Stair Inc.’ will continue to use bridged SSIDs, with local breakout into different VLANs.
The CTO of ‘No-Stair Inc.’ understands the need for you to ask additional questions to deliver the design. The questions may be sent in written form and will be answered within two weeks.
What is a possible constraint?

QUESTION 55
You are participating in a multi-team design workshop for a large enterprise campus and data center refresh project. The network engineering team has selected an EVPN-VXLAN-based fabric to support scalable Layer 2/3 services, improve segmentation, and streamline future automation.
As part of the session, you’ve been asked to contribute to the technical design recommendations document, which will serve as the foundation for the project’s implementation plan. This includes documenting best practices, control-plane design, and overlay requirements for the EVPN- VXLAN fabric.
You need to identify the accurate core recommendations, required features, and key design functions to be included in the proposal.
What accurately describe core recommendations, requirements, features, or functions of EVPN- VXLAN fabrics? (Choose two.)

QUESTION 56
‘Don’t Buy at Us’ is a US-based retail company that is expanding into Europe. They are expanding into EMEA with a regional headquarters called HQ2 inside The Netherlands.
Their US-based headquarters HQ1 was refreshed last year based on the HPE Aruba Networking ESP architecture. You have created the design for HQ2 based on the same design as HQ1, a two- tier architecture. The high level is shown below.

Switch BOM for this project based on Two Tier:
Collapsed Core: 2 x 8360-16Y2C in VSX (ISL 2x100GbE DAC)
Access Stack: 10 x Stack of 6200F 48G Class4 PoE 4SFP+ 740W (each stack has 4 members, VSF with 10GbE VSF links) (2 x 10GbE uplink per stack) Based on the scenario, which switch would be a good access layer switch to recommend?

QUESTION 57
A global cruise line company needs to refresh its current fleet. They win refresh the insides’ of the ship to be cost-effective and increase their sustain ability. They Mill replace the complete WLAN/LAN hardware of the ship. In this refresh, the company will not refresh Us current security requirements. The CIO also wants to limit the number of unused ports in the switches. Future expansion will always mean a refresh of hardware. They start with the smallest ship with a maximum of 800 guests Each ship has a LAN infrastructure consisting of two core switches, up to
10 redundant distribution switches, and up to 500 access switches (400 cabins. 100 technical rooms). The Core switches are located in the MDF of the ship and the distribution switches are located in the IDFs of the ship. Each cabin and technical room gets one single access switch. The cabling structure of the ship will not be refreshed. Each IDF is connected to the MDF by SMF. of which two pairs are available for the interconnect between the core and distribution. The length of SM fiber between MDF and IDF is less than 300 meters (930 ft) and the type used is 0S1. Each cabin is connected by a single 0M2 pair to the IDF. the maximum length is 60 meters (200 ft).
Each technical room is connected by a single 0M2 pail to the IDF. with lengths between 100 and
150 meters (320 and 500 ft).
For each cabin/technical room the customer is looking to replace their current fan-less 2530/2540 without changing the requirements, except they need to upgrade the uplink to distribution switch to 10GbEto handle the increased network traffic, and the technical rooms need redundant power.
The WLAN infrastructure will be 1:1 refreshed without new cabling or new AP locations. Their WLAN Infrastructure is based on the 200/300 series Indoor and outdoor APs running instantOS (less than 300 APs). the customer has no change in WLAN requirements. The cruise line company will replace its current Internet connection before the LAN/WLAN refresh. The new Internet connection will provide a 99.8% uptime, which is needed to ensure the paid guest Wi-Fi is always operational. With this new internet connection, the CIO of the cruise line wants to base the design on the ESP architecture from Aruba because Internet connection is guaranteed.
Based on the best practices and customer requirements, what is the correct WUN approach?

QUESTION 58
A large multinational financial institution has contracted you to design a new full-stack wired and wireless network for their new 6-story regional office building. The bottom two floors of this facility will be retail space for a large banking branch. The upper floors will be carpeted office space for corporate users, each floor being approximately 100,000 sq ft (9290 sq m). Data centers are all offsite and will be out of scope for this project. The customer is underserved by its existing L2- based network infrastructure and would like to take advantage of modem best practices in the new design. The network should be fully resilient and fault-tolerant, with dynamic segmentation at the edge.
The retail space will include public guest Wi-Fi access. Retail associates will have corporate tablets for customer service, and there will be a mix of wired and wireless devices throughout the retail floors. The corporate users will primarily use wireless for connectivity, but several wired clients, printers, and hard VoIP phones will be in use.
The customer is also planning on renovating the corporate office space in order to take advantage of ‘smart office’ technology. These improvements will drive blue-dot wayfinding, presence analytics, and other location-based services.
The client would like to ensure redundant RADIUS resources in each of their three geographical regions (AMER, EMEA, and APAC). A large office location is available in each region with sufficient VMware resources available.
– Each region has between 4,448 and 5,061 clients, all of which will need to do either 802.1X wired or wireless authentications as well as 802.1X authentication for a single personal device on Wi-Fi.
– All of the non-personal devices will also need to validate health with a local agent.
– A total of 500 guests are expected to be connected on average with a maximum of 700 simultaneous connections making use of Guest Portal for access to the Internet.
– TACACS authentication will also be configured for a total of 1200 evenly dispersed NADs.
How many OnGuard Licenses are required in this scenario?

QUESTION 59
A global cruise line company needs to refresh its current fleet. They win refresh the insides’ of the ship to be cost-effective and increase their sustain ability. They Mill replace the complete WLAN/LAN hardware of the ship. In this refresh, the company will not refresh Us current security requirements. The CIO also wants to limit the number of unused ports in the switches. Future expansion will always mean a refresh of hardware. They start with the smallest ship with a maximum of 800 guests. Each ship has a LAN infrastructure consisting of two core switches, up to 10 redundant distribution switches, and up to 500 access switches (400 cabins. 100 technical rooms). The Core switches are located in the MDF of the ship and the distribution switches are located in the IDFs of the ship. Each cabin and technical room gets one single access switch.
The cabling structure of the ship will not be refreshed. Each IDF is connected to the MDF by SMF. Of which two pairs are available for the interconnect between the core and distribution. The length of SM fiber between MDF and IDF is less than 300 meters (930 ft) and the type used is OS1. Each cabin is connected by a single OM2 pair to the IDF, the maximum length is 60 meters (200 ft). Each technical room is connected by a single OM2 pail to the IDF, with lengths between
100 and 150 meters (320 and 500 ft).
For each cabin/technical room the customer is looking to replace their current fan-less 2530/2540 without changing the requirements, except they need to upgrade the uplink to distribution switch to 10GbE to handle the increased network traffic, and the technical rooms need redundant power.
The WLAN infrastructure will be 1:1 refreshed without new cabling or new AP locations. Their WLAN Infrastructure is based on the 200/300 series Indoor and outdoor APs running instantOS (less than 300 APs), the customer has no change in WLAN requirements.
The cruise line company will replace its current Internet connection before the LAN/WLAN refresh. The new Internet connection will provide a 99.8% uptime, which is needed to ensure the paid guest Wi-Fi is always operational. With this new internet connection, the CIO of the cruise line wants to base the design on the ESP architecture from Aruba because Internet connection is guaranteed. Based on best practices, what should you recommend as the correct optic type for the connection between the IDF and the technical rooms?

QUESTION 60
Which is true when it comes to HPE Aruba Networking Central licensing for gateways?

QUESTION 61
What is the best practice for using VSX at the core of a 3-tier design?

QUESTION 62
A large multinational financial institution has contracted you to design a new full-stack wired and wireless network for their new 6-story regional office building. The bottom two floors of this facility will be retail space for a large banking branch. The upper floors will be carpeted office space for corporate users, each floor being approximately 100,000 sq ft (9290 sq m). Data centers are all offsite and will be out of scope for this project. The customer is underserved by its existing L2- based network infrastructure and would like to take advantage of modem best practices in the new design. The network should be fully resilient and fault-tolerant, with dynamic segmentation at the edge.
The retail space will include public guest Wi-Fi access. Retail associates will have corporate tablets for customer service, and there will be a mix of wired and wireless devices throughout the retail floors. The corporate users will primarily use wireless for connectivity, but several wired clients, printers, and hard VoIP phones will be in use.
The customer is also planning on renovating the corporate office space in order to take advantage of ‘smart office’ technology. These improvements will drive blue-dot wayfinding, presence analytics, and other location-based services.
The client has decided to market additional tools to its retail customers. The desire is to make a Blue Dot wayfinding app available to any customer to allow them to locate stores and services within the retail space. They would also like to have directed pop-ups within the app appear when a customer walks within close proximity to any of the 10 “Promotional Kiosks”.
What licensing will be needed to make this retail solution a reality? (Choose two.)
